Name: Self lubricating joint bearing standard parts
Brand: Arorotech
Availability: InStock
Rating: 5 (1 reviews)

Description

Domestic and foreign self-lubricating joint bearing and bushing standard system

Structure	System		Standard (Technical specification)
Bearing	China		GJB 5502
	Overseas	European standard	EN 2755
		American standard	SAE AS 81820
			SAE AS 81819

Table 4-1 Domestic and foreign standard systems of self-lubricating joint bearings and bushings

After years of research and development of self-lubricating joint bearings and self-lubricating bushings, our company has the ability to produce bearing products that meet the standards in Table 4-1.

In recent years, in order to continuously meet the needs of users, our company has gradually increased the study of foreign advanced bearing factories. For the bearing products of foreign samples (such as SARMAA, SKF, etc.), our company has the same production level and has repeatedly solved the urgent needs of users.

Standard system bearing product list

Structure	Technical Standard	Product structure	Unit
Bearing	GJB 5502	GB/T 9163	Metric
	GJB 5502	GB/T 9161	Metric
	EN 2755	EN 2585	Metric
		EN 4039	Metric
		EN 2584	Metric
		EN 4038	Metric
		EN 3048	Metric
		EN 4037	Metric
		EN 4040	Metric

Table 4-2 List of standard system bearing products

Bearing tolerance - inner ring tolerance

E、G、C、H series ring tolerance（μm）
d(mm)		△dmp		V dp	V dmp	△Bs
exceed	to	Upper deviation	Lower deviation	max	max	Upper deviation	Lower deviation
2.5	18	0	8	8	6	0	-120
18	30	0	-10	10	8	0	-120
30	50	0	-12	12	9	0	-120
50	80	0	-15	15	11	0	-150
80	120	0	-20	20	15	0	-200
120	180	0	-25	25	19	0	-250
180	250	0	-30	30	23	0	-300
250	315	0	-35	35	26	0	-350
315	400	0	-40	40	30	0	-400
400	500	0	-45	45	34	0	-450
500	630	0	-50	50	38	0	-500
Note: (1) : The tolerance values specified in this standard apply to rod end joint bearings after finishing but before coating, plating, splitting and cracking processes; (2) : rod end joint bearings with surface treatment, the tolerance is slightly different from the tolerance specified in this standard;

ring tolerance for K, W series（um)
d (mm)		△dmp		V dp	V dmp	△Bs
d (mm)		K、W				K		W
exceed	to	Upper deviation	Lower deviation	max	max	Upper deviation	Lower deviation	Upper deviation	Lower deviation
2.5	3	+10	0	10	6	0	-120	0	-100
3	6	+12	0	12	9	0	-120	0	-120
6	10	+15	0	15	11	0	-120	0	-150
10	18	+18	0	18	14	0	-120	0	-180
18	30	+21	0	21	16	0	-120	0	-210
30	50	+25	0	25	19	0	-120	0	-250
50	80	+30	0	30	22			0	-300
80	120	+35	0	35	26			0	-350
120	180	+40	0	40	30			0	-400
180	250	+46	0	46	35			0	-460
250	315	+52	0	52	39			0	-520
315	400	+57	0	57	43			0	-570
Note: (1) : The tolerance values specified in this standard apply to rod end joint bearings after finishing but before coating, plating, splitting and cracking processes; (2) : rod end joint bearings with surface treatment, the tolerance is slightly different from the tolerance specified in this standard;

Bearing tolerance - outer ring tolerance

Inner ring tolerances for E, G, C, H series（μm)
D（mm）		△Dmp		V Dp	V Dmp	△Cs
exceed	to	Upper deviation	Lower deviation	max	max	Upper deviation	Lower deviation
6	18	0	-8	10	6	0	-240
18	30	0	-9	12	7	0	-240
30	50	0	-11	15	8	0	-240
50	80	0	-13	17	10	0	-300
80	120	0	-15	20	11	0	-400
120	150	0	-18	24	14	0	-500
150	180	0	-25	33	19	0	-500
180	250	0	-30	40	23	0	-600
250	316	0	-35	47	26	0	-700
316	400	0	-40	53	30	0	-800
400	500	0	-45	6	34	0	-900
500	630	0	-50	67	38	0	-1000
Note: (1) : The tolerance values specified in this standard apply to rod end joint bearings after finishing but before coating, plating, splitting and cracking processes; (2) : rod end joint bearings with surface treatment, the tolerance is slightly different from the tolerance specified in this standard;

Inner ring tolerances for the K series（μm）
D（mm）		△Dmp		V Dp	V Dmp	△Cs
exceed	to	Upper deviation	Lower deviation	max	max	Upper deviation	Lower deviation
5	18	0	-11	18	18	0	-240
18	30	0	-13	21	21	0	-240
30	50	0	-16	25	25	0	-240
50	80	0	-19	30	30	0	-300
80	120	0	-22	35	35	0	-400
Note: (1) : The tolerance values specified in this standard apply to rod end joint bearings after finishing but before coating, plating, splitting and cracking processes; (2) : rod end joint bearings with surface treatment, the tolerance is slightly different from the tolerance specified in this standard;

Exceed	Name	符号	名称
B	Inner ring width	V dmp	Average bore variation
C	Outer ring width	V dp	Variation in inside diameter of a single radial plane
D	Bearing outside diameter	△Bs	Single width deviation of inner ring
d	Bearing bore diameter	△dmp	Single radial plane mean bore diameter deviation
d1	Outer diameter of inner ring face	△Dmp	Single radial plane mean outside diameter deviation
dk	Spherical diameter	v Dp	Variation in outside diameter of a single radial plane
α	Angle of inclination	v Dmp	Average outside diameter variation
r1min	Inner ring small one-way chamfer size	△Cs	Single width deviation of outer ring
r2min	Outer ring small one-way chamfer size

Table 4-3 Dimensions and tolerance symbols of joint bearings

Rod end joint bearing tolerance

E, G, C, H, K series rod end joint bearing tolerance（μm)
d (mm)		△dmp				V dp		V dmp		G		h、h1、h2	△Bs
d (mm)		E、EH G、GH		K		E、EH G、GH	K	E、EH G、GH	K	Comply with GB/T 197		E、EH、 G GH、K	E、EH、 G GH、K
Exceed	to	Upper deviation	Lower deviation	Upper deviation	Lower deviation	max		max		M Type	F Type		Upper deviation	Lower deviation
2.5	3	0	-8	10	0	8	10	6	6	6g	6H	±1200	0	-120
3	6	0	-8	12	0	8	12	6	9	6g	6H	±1200	0	-120
6	10	0	-8	15	0	8	15	6	11	6g	6H	±1200	0	-120
10	18	0	-8	18	0	8	18	6	14	6g	6H	±1200	0	-120
18	30	0	-10	21	0	10	21	8	16	6g	6H	±1200	0	-120
30	50	0	-12	25	0	12	25	9	19	6g	6H	±1200	0	-120
50	80	0	-15	30	0	15	30	11	22	6g	6H	±1200	0	-150
Note: (1) : The tolerance values specified in this standard apply to rod end joint bearings after finishing but before coating, plating, splitting and cracking processes; (2) : rod end joint bearings with surface treatment, the tolerance is slightly different from the tolerance specified in this standard; (3) : The thread can be right-handed or left-handed.

Exceed	Name	Symbol	Name
B	Inner ring width	l₁,l₃	Thread length
C	Outer ring width	l₂,l₄	Rod end length
C₁	Bar end eye width	l₅	Shoulder length
D	Bearing outside diameter	l₇	Length of bearing inner hole center to shank plane
d	Bearing bore diameter	r1min	Inner ring small one-way chamfer size
d₁	Outer diameter of inner ring face	r2min	Outer ring small one-way chamfer size
d₂	Outside diameter of rod end eye	V dmp	Average bore variation
d₃	Rod end shank diameter	V dp	Variation in inside diameter of a single radial plane
d₄	Shoulder diameter	W（1）	Width of opposite side
d_k	Spherical diameter	α	Angle of inclination
G	Thread diameter	△Bs	Single width deviation of inner ring
h,h1	Bar end center height	△dmp	Single radial plane mean bore diameter deviation
Note: (1) : This standard does not specify the width of the opposite side.

Table 4-4 Dimensions and tolerance symbols of rod end joint bearings

Product Description

AroroTech's Self-Lubricating Joint Bearing Standard Parts are designed to meet the rigorous demands of various industries, including automotive, industrial machinery, and mechanical systems. These bearings are manufactured in accordance with international standards such as EN 2755, SAE AS81820, and GJB 5502, ensuring compatibility and reliability across different applications.

Key Features:
Self-Lubricating Design: Incorporates solid lubricants like PTFE or graphite within the bearing material, eliminating the need for external lubrication and reducing maintenance requirements.
High Load Capacity: Engineered to withstand both radial and axial loads, making them suitable for high-load applications.
Durable Construction: Manufactured from high-quality materials such as 05Cr17Ni4Cu4Nb and G95Cr18, ensuring longevity and resistance to wear.
Precision Engineering: Built to exacting tolerances, these bearings provide smooth operation and minimal friction.
Compliance with International Standards: Manufactured in accordance with EN 2755, SAE AS81820, and GJB 5502 standards.

Applications:
Automotive Gear Systems: Used in car transmissions and other critical components to ensure reliable performance under high loads.
Industrial Machinery: Employed in machinery that requires robust bearings to handle heavy loads and high speeds.
Mechanical Systems: Integral to systems requiring precise motion control and durability.

As a leading bearing manufacturer and supplier, AroroTech offers high-quality Self-Lubricating Joint Bearing Standard Parts that meet international standards. Our products are trusted by gearbox manufacturers and industrial gearbox manufacturers worldwide for their reliability and performance.

Product Advantages

Maintenance-Free Operation: The self-lubricating design eliminates the need for external lubrication, reducing maintenance costs and downtime.
High Load Capacity: Designed to handle both radial and axial loads, ensuring stability in demanding applications.
Enhanced Durability: Constructed from high-quality materials with advanced heat treatment processes to resist wear and corrosion.
Precision Engineering: Manufactured to strict tolerances, providing smooth operation and minimal friction.
Compliance with International Standards: Manufactured in accordance with EN 2755, SAE AS81820, and GJB 5502 standards, ensuring compatibility and reliability across different applications.

Application Scenarios

AroroTech's Self-Lubricating Joint Bearing Standard Parts are widely used in various industries, including:
Automotive Industry: Employed in gear systems, wheel bearings, and other critical components to ensure smooth operation and durability.
Industrial Machinery: Utilized in machine tool spindles, pumps, and compressors where high precision and load handling are essential.
Mechanical Systems: Integral to systems requiring precise motion control and durability, such as robotics and automation equipment.

These bearings are essential for applications that demand high performance and reliability, making them a preferred choice among bearing manufacturers and suppliers.
